کلید شستی استیل سبز LED دار قطر 12V/24V – 16mm

سوئیچ پوش باتون فشاری (push) سایز 16 میلی متری تمام استیل گرد فلزی

کیفیت بالا و مرغوب، بدنه ضدآب و ضدزنگ با طراحی زیبا اتصال لحظه ای

کلید آسانسوری مهره خور فلزی رنگ بدنه نقره ای و رنگ چراغ LED سبز

دارای 5 پایه تمام مس و یک مهره فلزی و واشر پلاستیکی

ولتاژ 12 ولت و 24 ولت و جریان 6 آمپر ماکزیمم 12V/24V – 6A

>> ابعاد دقیق قابل مشاهده در تصاویر محصول – پارت نامبر : hsc16f-11e/j/n

** این مدل شستی به صورت پوش باتون می باشد. یعنی با نگه داشتن و رها کردن عمل می کند. مانند زنگ منازل

————————————–

>> Waterproof Push Button Switch 16mm Latching Switch 12V/24V 3A Brass 5 Pin with Blue Ring LED Light for Car Boat Motorcycle

>> About this item

• Latching Push Button Switch: 16mm Panel mounting hole size, 14mm push button diameter, Push: Power ON, Release your finger: Power OFF. Lifetime up to 100,000 cycles, enough for a long time use.
• Sturdy and Durable: Our push button switch made of Chrome Plated Brass with PA66 nylon base, rust and corrosion resistance, good flame retardancy and insulation, stable and durable, easy to maintain.
• Waterproof and Dustproof: Pressure switch equipped with hexagon nut and O-shaped waterproof ring, offer IP65 and IK08 protection, heat resistance, freely used in the wet or dusty environment.
• Easy to Install: No welding required, Just pass the wire through the screw hole at the bottom of the switch and fix it with a rotating thread. Blue LED light can be on constantly or instantaneously, depending on your connection method.
• Wide Application: Widely used in cars, trucks, ships, ignition systems, home doorbells and switch panels. Ideal for circuit control in electromagnetic starters, contactors, relays and other circuits.

1. Stainless steel material for long-term use
2. Inbuilt Colorful Ring illumination LED
3. Available in Various LED Color
4. Bright daylight LEDs
5. Single pole push to make and Push to break Function
6. Front and rear panel seal to IP67 & TVS protection
7. Rubber ring and hexagon nut to fix, Waterproof and Dustproof

About this item

• Mounting hole size:16mm, 5 Copper Pin Switch. green LED Light.
• Operation type Momentary: Pressing the button ON, Release the button OFF.
• Switch rating:2A/36VDC, LED can be ON all the time or only ON when switch is ON, depending on how you wire it.
• Switch LED max voltage: 12V (when the voltage is higher than 3V, you need to add external resistor.)
• Strong and durable, Degree of protection: waterproof IP67,IK08.
